DALI DT6 LED Driver with Terminal for Magnet Track Light SRP-2305-MT-48VCC100-700T

The DALI DT6 LED driver with terminal features a super-slim design, tailored for magnet track lighting and linear lighting systems. Utilizing magnetic absorption for installation, it ensures quick setup without any high-frequency interference sounds. This controller operates with a DC48V input and delivers a maximum output power of 28W. It provides a single channel with a constant current output range of 100-700mA, with dipswitches for selecting multiple operational currents. The device offers deep, smooth dimming down to 0.1%, providing a flicker-free experience. Compliant with IEC 62386-101:2014, IEC 62386-102:2014, and IEC 62386-207 Ed2 standards, it integrates seamlessly with all DALI systems on the market. Equipped with a built-in DALI-2 interface, the DT6 is designed for maximum compatibility and performance. With an IP20 waterproof rating and a 5-year warranty, this LED controller ensures long-lasting, reliable use in a variety of settings.

Key Features

• Super slim design DALI DT6 LED controller
• Special design for magnet track light and linear lighting
• Magnet absorption installation application, no high frequency interference sound
• DC48V input, max. output power 28W total
• 1 channel 100-700mA constant current output, dips to select multi operation current
• Deep and smooth dimming to 0.1%, flicker free
• In compliance with IEC 62386-101:2014, IEC 62386-102:2014, IEC 62386-207 Ed2.
• Built-in DALI-2 interface, DALI DT6 device
• Match all DALI systems in the market
• Waterproof grade:IP20
• 5 years warranty

Function Introduction

Материалы для скачивания

• SRP-2305-MT-48VCC100-700T User Manual.pdf
