Sunricher, Реле, 4 Канала, 4x16A DIN Rail DALI DALI-2 Relay Switch SR-DARM16-DIN4
Копировать ссылку на товар
Ссылка успешно скопирована!
Артикул: SR-DARM16-DIN4
Наличие на складах:
| 1) Склад на Бумажном: | 17 шт. |
| 2) Склад удалённый: | 0 шт. |
25 103 ₽
DALI-2 certified 4-channel relay module for DIN rail installation, designed to control standard contactors via DALI. Supports 100–240VAC, enables integration of non-DALI loads, features zero-crossing detection for extended relay life, and is compatible with universal DALI systems.
Key Features
• DALI relay module, DALI-2 certified
• DIN rail installation
• 100-277VAC power supply
• 4 channels relay module
• Control of 4 standard contactors
• DIN rail relay module for controlling 4 standard contactors via DALI
• Loads that do not have a DALI input can therefore be integrated in the DALI circuit
• The loads can be switched on and off via DALI
• With zero crossing detection, the relay switching life cycle greatly increased
• Compatible with universal DALI systems and master controllers in the market
• DIN rail installation, compatible with standard 35mm DIN rail
• 5 years warranty
• Waterproof grade: IP20
Specifications
| DALI control | DALI | Number of DALI | Switching voltage | Switching voltage | Current | Type of |
|---|---|---|---|---|---|---|
| 1 | < 3mA | 4 | Max. 250V | Max. 30V | Resistive load: max. 4*16A | 4 normally |
Function Introduction
Руководство по эксплуатации EN (PDF)
